Problem I. Design and Analysis of Algorithms (40 points)
Consider the problem of an operator (e.g., a restaurant waiter, an office clerk, a computer processor, ...) sequentially serving n customers C1,...,Cn each having a given duration time of service, duration[i]. Write an algorithm that produces an optimal service schedule, in which each customer receives a start-of-service[i] time that allows the customer to be served for the necessary amount of time, and that minimizes the average wait of all customers, which is (1/n)*Σni=1 start-of-service[i]. Assume that the operator and all the customers are ready to start at time 0.Input:
- n: The number of customers.
- A 1-dimensional array: duration[1...n] such that for all i, 1 ≤ i ≤n, duration[i] is the amount of time (in minutes) that the actual service to customer i will take.
- A 1-dimensional array: start-of-service[1...n] such that for all i, 1 ≤ i ≤n, start-of-service[i] is the time (= minute) when customer i will start being served. (Equivalently, start-of-service[i] is the number of minutes that customer i will have to wait before being served, since we start time at 0.)
- (5 points)
Describe in detail the strategy you will use to solve this problem.
Solution:
I'll use a greedy algorithm with a selection criterion that chooses as the next customer to be served, the customer with the shortest duration among those who haven't been served yet.
- (15 points)
Write your algorithm (in pseudo-code) here.
Remember that you need to keep track of
the customers, so that at the end, start-of-service[i] corresponds
to the same customer i whose input was duration[i].
Solution 1:
/* I'll use a priority queue PQ to store the customers, using their duration value as their key. */ Instruction #Iterations Total { StartHeap(PQ) O(1) For each i := 1 to n do { O(1) * n = O(n) Insert customer i with key duration[i] in PQ O(log(n)) * n = O(nlog(n)) } time := 0 O(1) For each i := 1 to n do { O(1) * n = O(n) nextcustomer := ExtractMin(PQ) O(log(n)) * n = O(nlog(n)) start-of-service[nextcustomer] := time O(1) * n = O(n) time := time + duration[nextcustomer] O(1) * n = O(n) } } ----------- T(n) = 2*O(1) + 4*O(n) + 2*O(nlog(n)) = O(nlog(n))
Solution 2:
/* An alternate solution can be constructed similary by sorting the customers in increasing order by their duration time, using an O(nlog(n)) sorting algorithm, like mergesort. Care should be taken to keep track of the original number of the customer, so that the output start-of-service[i] corresponds to the original custormer i. For that, I'll use an array name_duration_array[1...n] that stores in each of its cells an object (pair) that consists of two parts: (1) the customer number, and (2) his/her duration time.
Instruction #Iterations Total { For each i := 1 to n do { O(1) * n = O(n) name_duration_array[i] := (i,duration[i]) O(1) * n = O(n) } Use mergesort to sort name_duration_array[1...n] O(nlog(n)) in increasing order according to the 2nd component of the pair in each cell (i.e., duration) time := 0 O(1) For each k := 1 to n do { O(1) * n = O(n) Let name_duration_array[k]=(i,duration[i]) O(1) * n = O(n) start-of-service[i] := time O(1) * n = O(n) time := time + duration[i] O(1) * n = O(n) } } ----------- T(n) = O(1) + 6*O(n) + *O(nlog(n)) = O(nlog(n))
- (10 points)
Rigorously prove that the algorithm is correct and optimal.
That is, prove that it outputs a valid start-of-service[1...n] array
in which all customers are sequentially served,
each customer is served for the necessary amount of time,
and
the average wait of all customers,
(1/n)*Σni=1 start-of-service[i],
is the minimum possible.
Solution:
- All customers are served, with customer i begin time equal to start-of-service[i].
- Each customer i is scheduled to be served for the entire duration[i], as the variable "time" was incremented by duration[i] after scheduling customer i.
- Let's show that this greedy algorithm produces the optimal solution.
Let the input costumers be C1,C2,...,Cn with durations D1,D2,...,Dn,
and let the output be their assigned starting times S1,S2,...,Sn.
- Alternate Proof 1:
The starting time Si of customer Ci is determined by our algorithm to be:
Si = start_of_service[i]= Σall customers j with (Dj < Di) OR (Dj=Di && j < i) Dj. Since we are making each Si as small as possible, then their average (1/n)*Σni=1 Si will be as small as possible. - Alternate Proof 2:
Assume by way of contradiction that the sequence S1,S2,...,Sn
output by our algorithm is not optimal.
Then, there is a different sequence
R1,R2,...,Rn
that has a lower average than that of S1,S2,...,Sn.
Let's sort each of these sequences of starting times in increasing order:
Sk1,
Sk2,...,
Skn
and
Rm1,
Rm2,...,
Rmn.
Let j be the first position in which they differ (j &ge 1):
Sk1,Sk2,...,Sk(j-1),Skj,...,Skn Rm1,Rm2,...,Rm(j-1),Rmj,...,Rmn |---------------| the two sequences coincide here
Since Skj ≠ Rmj, then either:- Rmj < Skj:
Let's consider the sequence of customers who would be served before index j:
Ck1, Ck2,..., Ck(j-1) in the S-sequence Cm1, Cm2,..., Cm(j-1) in the R-sequence For each i, 1 ≤ i ≤ (j-1), we must have that duration of Cki = duration of Cmi.
Since our algorithm is such that Skj = Sk(j-1) + duration[Ck(j-1)], then the R-sequence doesn't give enough time to fully service customer Cm(j-1) and therefore is not a correct solution to this problem. - Rmj > Skj: Then the R-sequence is wasting the time interval Skj - Rmj and unnecessarily increasing its average, so it cannot be optimal. Our S-sequence is staying ahead of it!
In both cases we conclude that the R-sequence cannot be an optimal solution to this problem contradicting our original assumption, and therefore the S-sequence output by our algorithm is optimal.
- Rmj < Skj:
Let's consider the sequence of customers who would be served before index j:
- Alternate Proof 1:
The starting time Si of customer Ci is determined by our algorithm to be:
- (10 points)
Analyze the runtime of your algorithm as a function of n.
Provide a runtime function T(n)
and the tightest asymptotic upper bound g(n) you can such that
T(n)=O(g(n)).
[You can do so above neatly next to each instruction of the algorithm,
or below in the space provided.]
Solution:
See runtime analysis above, together with the algorithm(s).
Problem II. Time Complexity (20 points)
- (10 points)
Let A and B be two algorithms with runtimes
TA(n) = loga(n) and
TB(n) = logb(n), respectively, where
a and b are two (possibly different) constants a,b > 1.
Prove that TA(n) = Θ(TB(n)).
[Hint: use the fact that loga(n) = logb(n)/ logb(a) ]
Solution:
TA(n)
= loga(n)
= logb(n)/ logb(a)
= [1/logb(a)]*logb(n)
= k*logb(n) where k = 1/logb(a) is a constant (note that logb(a) > 0 since a,b > 1)
= Θ(logb(n))
= Θ(TB(n))
- (10 points)
Let A and B be two algorithms with runtimes
TA(n) = nloga(c) and
TB(n) = nlogb(c), respectively, where
a, b, and c are (possibly different) constants a,b,c > 1.
Show that TA(n) might not be Θ(TB(n)) by choosing specific values for the constants a, b, and c (e.g., a=2) such that TA(n) is NOT Θ(TB(n)). Justify your answer.
[Hint: Remember that loga(u) = x if and only if ax = u]
Solution:
Take a = 2, b = 4, c = 16. Then,- TA(n) = nloga(c) = nlog2(16) = n4
- TB(n) = nlogb(c) = nlog4(16) = n2
- (1) the base is smaller than 1;
- (2) the base is not constant (e.g., logn, logsqrt(n)); or
- (3) the logarithm is in the exponent (e.g., nloga(c), 2loga(n)).]
Problem III. Design and Analysis of Algorithms (40 points)
Let G=(V,E) be a directed graph. We say that G is a directed acyclic graph (DAG) if it does NOT contain any directed cycles. The graph on the left in the figure below is a DAG. The same graph has been drawn differently on the right to show explicitly that it doesn't contain any directed cycles.A topological ordering of a directed acyclic graph G=(V,E) is an ordering of its nodes as v1, v2, ., vn so that for every edge (vi, vj) we have i < j. We have added labels v1,...,v7 to the nodes in the depicted graph to show that this graph has a topological ordering of its nodes (imagine that initially, the nodes in G were named 1,...,n in no particular order). Graphically, all edges in the topological ordering of the graph go "from left to right".
Indeed, it is true that there exists a topological ordering for any directed acyclic graph. In this problem, you'll construct an algorithm that given a DAG, will output a topological ordering of its nodes. The desired runtime of the algoritm is O(n+m), where n is the number of nodes and m is the number of edges.
Input:
- A directed acyclic graph G(V,E) containing n nodes and m edges, represented by an adjacency list.
Output:
- A 1-dimensional array: topological_ordering[1...n] such that for all i, 1 ≤ i ≤n, topological_ordering[i] = the ith node in a topological ordering of G.
Algorithm:
- The strategy that we will use to solve this problem is based on the
following observation: In a DAG, there is always at least one node
that has no incoming edges. Check the graph depicted to see that this
is the case.
A very general sketch of the algorithm is as follows:
Repeat Find a node u in G with no incoming edges Make u the first element of (or the next element if some nodes have already been added to) the topological ordering of G "Remove" node u from G ("G - u" will continue to be a DAG) Until all nodes in G have been added to the topological orderingMaintain the following information:
- incoming_count[1...n] where incoming_count[w] = remaining number of incoming edges to node w
- S = set of remaining nodes with no incoming edges
In order to "remove" a node u from G it suffices to:
- remove u from S (in O(1) time)
- decrement incoming_count[w] for all edges from u to w, and add w to S if incoming_count[w] hits 0.
- (25 points)
Write your algorithm (in pseudo-code) here.
Remember that your algorithm should run in O(m+n) time.
Solution:
Both the algorithmm and its analysis here rely on the fact that the graph is represented by an adjacency list, and that the set S is represented with a list for which adding or removing the 1st element takes O(1) time.{ Instruction #Iterations Total /* Initialization */ For each node u in G do { O(1) * n = O(n) incoming_count[u] := 0 O(1) * n = O(n) } For each node u in G do { O(1) * n = O(n) For each edge (u,w) adjacent to u do { O(1) * m = O(m) incoming_count[w] := incoming_count[w]+1 O(1) * m = O(m) } } S := empty list = O(1) For each node u in G do { O(1) * n = O(n) if incoming_count[u] = 0 then { O(1) * n = O(n) Add u as the first element of S O(1) * n = O(n) } } i:= 1 = O(1) /* end of initialization */ While S is not empty do { O(1) * n = O(n) u := first element in S O(1) * n = O(n) topological_ordering[i] := u O(1) * n = O(n) For each edge (u,w) adjacent to u do { O(1) * m = O(m) incoming_count[w] := incoming_count[w]-1 O(1) * m = O(m) if incoming_count[u] = 0 then { O(1) * n = O(n) Add u as the first element of S O(1) * n = O(n) } } i := i + 1 O(1) * n = O(n) } return topological_ordering[1..n] ≤ O(n) -------- T(n) = 2*O(1) + 11*O(n) + 4*O(m) = O(m + n) }
- (15 points)
Show that the runtime of your algorithm
is O(m+n). [You can do so above neatly next to each instruction of the algorithm,
or below in the space provided.]
Solution:
See runtime analysis above, together with the algorithm.
